Product model: 25 m3 / h, 60 m3 / h, 120 m3 / h, 280 m3 / h
Ceramic filter in detail
Ceramic filter is also called the ceramic filtering tank, it is a kind of fast and efficient filtration equipment, after the clogging the filter material, in does not affect the normal work condition, can use the system to flush the filter material, and restore the function of filtering equipment of high precision equipment. Automatic separation; Installation is simple, cover an area of province; Resistance to high temperature and high pressure, acid and alkali corrosion resistance; High precision filter; Thoroughly efficient recoil, long service life; Reliable operation, simple maintenance; Can be widely used in petrochemical, metallurgy, food, brewing, pharmaceutical, and other fields of solid-liquid separation, gas purification, water treatment, etc.
Ceramic filter points:
1, high filtration efficiency, oil removal rate up to 80-95%, particle size greater than 5 um suspended solids removal rate of 90% or so;
2, high efficiency regeneration: a simple rapid gas-liquid the jetting blocked ceramic filter can be effectively and rapidly renewable, ceramic filter service life is long;
3, resistance to chemical corrosion performance of the special superiority; All kinds of acid, alkali, salt resistance, resistance to most organic solvents under 70 ℃, tasteless, non-toxic, no foreign body dissolution;
4, the thermal stability of performance: the filter material thermal stability of 200-20 ℃ three cracks;
5, filtration precision and filtration rate: with the porous medium of average pore diameter, wall thickness, stoma filter differential pressure is related to such factors as the material parameters, need through the experiment and calculation to determine correctly, can be in 5 to 10 MB/s speed by filtration.
Ceramic filter main use:
1, within the field of environmental protection, wastewater after chemical coagulation, flocculation, filtration, sludge dewatering; Ion exchange method, electrolytic method, active carbon adsorption method to deal with the pretreatment of the wastewater; Suspended solids in waste water boiler wet dust removal filter processing (which can realize closed cycle); Evaporation and concentration of air flotation and terminal handling; Oily waste water of oil water separation process; Various flue gas filter, etc.
2, this filter is suitable for the particularly toxic medium in the liquid solid separation of suspended particles and oil;
3, can be widely used in water treatment, metallurgy, petroleum, chemical, power, light industry, food, medicine, textile, paper making, coking and iron and steel industry production needs to be recycled.
Ceramic filter main specifications:
Type no. TLG TLG TLG - 1-2-3 TLG - 4
Design pressure drop (mpa) 0.06 0.06 0.06 0.06 or less or less or less or less
Flow (m3 / h) and 60, 120, 280
Filtration precision (including m) 0.2 0.2-50-50-100-0.5-0.2 100
Suspended solids removal ﹪ 95 95 90 90
Design pressure (mpa) 1.2 1.2 1.2 1.2
(efficiency: a liquid suspended 5 mg/L, or less oily 10 mg/L or less of produced liquid, gas flow is liquid flow of 6-10 times)
Ceramic filters are used for:
Oilfield water flooding back processing technology;
Water treatment, industrial water, desalination of filter;
Rolling emulsion wastewater;
Organic wastewater after biochemical treatment, and secondary precipitation after filtration;
Metal lotion, electroplating wastewater treatment and recycling;
Tetracycline in the production of crystal filter;
The water filter in hydrogen peroxide production;
Film production impurities in the filter;
Lithopone production of zinc sulfide in the filter.
